The Powertec 4G-5G Ceiling Dome Antenna, 698 to 4000 MHz, N Female offers exceptional performance for both 4G and 5G networks. This high-gain antenna is ideal for enhancing signal strength within buildings, ensuring reliable connectivity for a variety of indoor applications.

Key Features:

• 2 dBi gain across lower bands 698 to 960 MHz
• 5 dBi gain across mid-bands 1695 to 4000 MHz
• Vertical Polarisation
• Low PIM RG-402 cable tail with N female connector
• 50 Ω Input Impedance
• 50W max. Input Power
• DC Ground Lightning Protection

Broad Frequency Range

Designed to operate across an extensive frequency spectrum, this antenna supports frequencies from 698 MHz to 4000 MHz. It provides optimal signal reception and transmission for both 4G and 5G networks, making it a versatile choice for modern communication needs.

High-Gain Performance

The Powertec Ceiling Dome Antenna features impressive gain levels, with 2.0 dBi at lower frequencies (698-960 MHz), 5.0 dBi in the mid-range (1710-2700 MHz), and 5.5 dBi at higher frequencies (3300-4000 MHz). This high-gain performance ensures strong and stable signal coverage throughout your indoor space.

Excellent Beamwidth and Polarisation

Offering a horizontal beam width of 360° and vertical beam widths of 85°, 54°, and 28° across different frequency ranges, this antenna provides comprehensive coverage. The vertical polarisation ensures optimal signal alignment for various communication devices.

Durable and Reliable Construction

Constructed with a UV-stabilised ABS radome and an aluminium reflector, this antenna is built to withstand harsh conditions. It operates effectively within a temperature range of -40 °C to +65 °C, making it suitable for various indoor environments.

Low PIM for High-Quality Signal

The antenna features a low Passive Intermodulation (PIM) performance, with a third-order PIM level of ≤-150 dBc at 2×20W. This ensures minimal signal interference and maintains high-quality communication, essential for maintaining clear and reliable connections.

Easy Installation and Compatibility

With a compact size of Ø186 x 86 mm and a lightweight design of just 0.25 kg, this ceiling dome antenna is easy to install. It comes with an N Female connector, ensuring compatibility with a range of equipment, and includes DC ground lightning protection for added safety.
