The TECO 2.8kW Inverter Window/Wall Air Conditioner is designed to deliver efficient and reliable cooling and heating for small to medium spaces. Featuring a compact design, this unit seamlessly integrates into any home or office setting. Its eco-friendly R32 refrigerant, coupled with the latest Inverter technology, ensures optimal energy performance and comfort all year round. Perfect for bedrooms or living spaces, this air conditioner offers intuitive operation through user-friendly electronic controls and a wireless remote.

  • Cooling Capacity: 2.8kW – Ideal for small to medium spaces.
  • Heating Capacity: 2.43kW – Efficient performance even in low temperatures.
  • Gold Fin Protection: Enhances durability by resisting corrosion.
  • High-Density Filters: Reduces fine particles for cleaner indoor air.
  • Electronic Control with Remote Controller: Manage your air conditioning with precision using a responsive remote and intuitive electronic controls.
  • Intelligent Preheating: Automatically prepares the system for optimal heating, ensuring consistent warmth on chilly mornings.
  • Filter Dirty Alarm: Stay on top of maintenance with an alert that reminds you to clean or replace your air filter.
  • Auto Fan Function: Adjusts fan speed automatically for consistent airflow and temperature balance.
  • Low Voltage Startup: Operates efficiently even during voltage fluctuations, protecting the unit and ensuring uninterrupted performance.
  • Silver Ion Sterilising Filter: Advanced filtration technology neutralises harmful bacteria and allergens for healthier indoor air.
TECO INVERTER WINDOW WALL AIR CONDITIONER — 2.8kW
TECO Model — TWW28HVAG
TECO EAN Code — 9346998006732

Power Supply

 Rated Voltage V 220-240
Rated Frequency Hz 50
Phases — 1
Cooling Capacity W 2800
Cooling Capacity Range W 2800(Rated)/1450(Mid)
Cooling Power Input W 850
Cooling Power Input Range W 850(Rated)/420(Mid)
Cooling Power Current A 4.5
Cooling Power Current Range A 4.5(Rated)/2.08(Mid)
Heating Capacity W 2430
Heating Capacity Range W 2400(Rated)/1220(Mid)
Heating Power Input W 770
Heating Power Input Range W 780(Rated)/330(Mid)
Heating Power Current A 4.5
Heating Power Current Range A 4.5(Rated)/1.7(Mid)
EER W/W 3.2941
AEER W/W 3.2426
Cooling Star Rating (Hot / Mixed / Cold)   2.5/2/2
Cooling Energy Consumption (Hot / Mixed / Cold) kWh/year 892/304/202
COP W 3.1558
ACOP W 3.1015
Heating Star Rating (Hot / Mixed / Cold)   1.5/0.5/0.5
Heating Energy Consumption (Hot / Mixed / Cold) kWh/year 71/559/1533
Noise (Energy Label – Indoor / Outdoor) dB(A) 60/66
Rated Input (Max) W 1250
Rated Current (Max) A 7
Inactive Energy (Avg) W 4
Air Flow Volume(H/M/L) m3/h 420/380/340
Air Flow Volume(H/M/L) L/s 117/106/94
Air Flow Volume(H/M/L) CFM 247/224/200
Dehumidifying Volume L/h 1.6
Dehumidifying Volume Pint/h 3.38
Application Area m2 16-24
Permissible Excessive Operating Pressure for the Discharge Side MPa 4.3
Permissible Excessive Operating Pressure for the Suction Side MPa 2.5
Maximum Allowable Pressure MPa 4.3
Climate Type — T1
Isolation — I
Moisture Protection — IPX4<outdoor>
Evaporater Coil Hydrophilic Coating — Blue
Condensor Coil Hydrophilic Coating — Gold
Dimension (W×H×D) mm 560x375x708
Recommended Cut Out Size (W×H) mm 565×380
Dimension of Carton Box (L×W×H) mm 803x620x410
Dimension of Package (L×W×H) mm 806x623x425
Net Weight kg 38
Gross Weight kg 41
Stacking layers   6
Refrigerant — R32
Refrigerant Charge kg 0.55

Indoor Side

 Fan Type   Centrifugal
Set Temperature Range ℃ 16～30
Sound Pressure Level (H/M/L) dB (A) 49/47/45
Sound Power Level (H/M/L) dB (A) 59/57/55

Outdoor Side
Cooling Operation Ambient Temperature Range ℃ 18～43
Heating Operation Ambient Temperature Range ℃ -7～24
Sound Pressure Level (H/M/L) dB (A) 58/56/54
Sound Power Level (H/M/L) dB (A) 68/66/64
Container Loading Quantity (20GP/40GP/40HQ)   125/260/312

Electronic Control with Remote Controller YES

General Function

 Auto YES
Cooling YES
Heating YES
Dehumidify YES
Sleep YES
Timer YES
Auto Swing (Horizontal Auto Swing) YES
Air Flow YES
Memory YES
Auto Fan YES
Filter Dirty Alarm YES
Soft Start YES
Low Voltage Startup YES
Intelligent Preheating YES
Auto Restart YES
Self Diagnosis YES
Silver Ion Sterilizing Filter YES
SKU TWW28HVAG
Barcode # 9346998006732
Brand TECO
