Applications

• Bore water extraction in rural and agricultural settings
• Deep well irrigation systems
• High‑head water transfer from deep sources

Technical Specifications

• Power: 2 HP
• Maximum Head: 132 m
• Maximum Flow: 67 L/min (4 m³/h)
• Motor Speed: 2900 rpm
• Fitting Size: 1.25"
• Voltage: 220‑240 V ~50 Hz
• Diameter: 4"
• Material: Stainless steel impeller and diffuser
• Ingress Protection: IP68
• Included Cable: 40 m SAA‑certified cable
• Weight (Net/Gross): 24.2 kg / 26.8 kg
• Dimensions (H x L x W): 150mm x 1040mm x 310mm
• Weight: 26.8 kg

Key Features

• High‑head capability — 132 metres for deep bore applications
• Durable stainless steel impeller and diffuser for corrosion resistance
• Full submersion rated — IP68 for reliable operation underwater
• Includes 40 metre SAA‑certified power cable and control box — ready for professional installation
• Robust 2 HP motor delivering up to 67 L/min
