Applications

• Domestic and rural water pump systems
• Turbocharging and thermal expansion systems
• Water hammer protection
• Small booster and irrigation systems

Technical Specifications

• Nominal Volume: 2 L
• Liner Material: Natural polypropylene
• Diaphragm Material: High‑grade butyl rubber
• Inlet Connection: Stainless steel pipe
• Air Valve: Brass valve with threaded O‑ring bonnet
• Exterior Coating: Epoxy undercoat with dual‑layer polyurethane paint
• Testing: Multi‑stage production line quality testing
• Dimensions (H x L x W): 360mm x 260mm x 260mm
• Weight: 1.0 kg

Key Features

• Compact 2 L volume ideal for pump protection and water‑hammer mitigation
• Natural polypropylene liner and butyl rubber diaphragm for corrosion resistance
• Brass air valve with O‑ring bonnet to prevent air leakage
• Steel lock ring secures internal components
• UV‑protected exterior finish for long‑term outdoor use
• Multi‑stage testing ensures structural integrity
