The Ruijie Reyee RG-EST350 (V2) is designed to effortlessly transmit data over distances of up to 5 km in real time. This high-performance wireless bridge utilises advanced Wi-Fi 5 technology (IEEE 802.11ac, Wave2) to deliver reliable connectivity, making it an ideal solution for various applications, including remote surveillance and data transfer.

Key Features:

• Capable of transmitting data from up to 5 km away in real time
• Factory-paired bridges for easy long-distance installation
• IP54 weatherproof rating
• Monitoring available via Ruijie cloud
• Wi-Fi 5 (IEEE 802.11ac, Wave2)
• Dual-stream technology
• 2×2 MIMO and MU-MIMO support
• 15 dBi directional antenna gain
• 2x 10/100/1000 Base-T fixed ports
• Adjustable transmit power of ≤400 mW (26 dBm)
• CE and RoHS certified

Effortless Installation with Factory-Paired Bridges

Simplifying the installation process, the RG-EST350 V2 comes as a factory-paired bridge system, eliminating the need for complex alignment. This feature allows users to set up long-distance connections with ease, ensuring that the devices work seamlessly from the moment they are unpacked.

Robust Weatherproof Design

Built to withstand challenging environmental conditions, the RG-EST350 V2 features an IP54 weatherproof rating. With an operational temperature range of -30 °C to 65 °C, this wireless bridge guarantees stable performance, ensuring connectivity in both extreme heat and cold.

High Capacity for Camera Support

This wireless bridge can support significant data loads, making it suitable for security and surveillance applications. It can handle up to 45 × 2 MP cameras at a distance of 3 km, or 20 × 2 MP cameras at the maximum range of 5 km, providing flexibility for various monitoring needs.

Comprehensive Remote Monitoring

With visually intuitive statistics monitoring on Ruijie Cloud, users can easily manage their network and maintain devices remotely. This feature enhances operational efficiency by providing real-time insights and simplifying troubleshooting processes.

Enhanced Data Transfer Speeds

Equipped with a maximum wireless speed of 867 Mbps and 15 dBi directional antenna gain, the RG-EST350 V2 ensures fast and stable connections. This performance is ideal for applications requiring high bandwidth, such as video streaming and data-intensive tasks.

Compact and Lightweight Design

Weighing only 0.5 kg and with dimensions of 230 mm x 132 mm x 48 mm, the RG-EST350 V2 is designed for easy installation and minimal footprint. Its compact design allows for versatile mounting options, ensuring that it can fit seamlessly into various deployment scenarios.
